Engine Parts Ultrasonic Cleaner

Engine parts ultrasonic cleaner is economy, low operating costs and easy to operate, man-machine dialogue model to help you quickly and easily complete the cleaning task. The engine parts ultrasonic cleaner installation is only a few steps, it can be placed in almost all production areas.

Send Inquiry

Product Description

China Customized Engine Parts Ultrasonic Cleaner Suppliers

1.Engine Parts Ultrasonic Cleaner Introduction

Engine parts ultrasonic cleaner is economy, low operating costs and easy to operate, man-machine dialogue model to help you quickly and easily complete the cleaning task. The engine parts ultrasonic cleaner installation is only a few steps, it can be placed in almost all production areas.

We focus on developing and research easy operating engine parts ultrasonic cleaner. To ensure customers have benefits from high-tech ultrasonic cleaning technology. M series ultrasonic cleaning equipment can expand or refit on existing cleaning equipment.

Clangsonic fully automatic ultrasonic cleaning equipment, available in 5 different standard size, the single tank size: 50L/85L/120L/160L/220L, other sizes can be made as requests. Ultrasonic frequency available in both single frequency and dual-frequency 25/45kHz, 28/68kHz, 40/80kHz, 40/130kHz and 80/130kHz. The unit is equipped with an oscillation device for the cleaning basket which assists and improves the cleaning effect of the ultrasound, and which also provides a drip off support for the stainless-steel basket. The units of Clangsonic M series can be combined with a rinsing tank (with /without heating) and a hot air dryer of the relevant size. The units are delivered including support frame.





Engine Parts Ultrasonic Cleaner

Clangsonic provides varies of capacities of ultrasonic cleaner. Please contact us for customized tank size.


2.Engine Parts Ultrasonic Cleaner Parameter(Specification)

Name 3-Tank Ultrasonic Cleaning Line
Model M813
Overall Size 3200x1600x1800mm
Single Tank Inner Size 450x400x450mm
Basket Size 370x320x260mm
Basket Loading Capacity 25KG
#1 Tank 28/68kHz Ultrasonic Cleaning
#2 Tank 40/80kHz Ultrasonic Rinsing
#3 Tank Hot Air Drying Tank
Heating Power For #1 and #2 Tank 6000W
Heating Power For #3 Tank 8000W
Power Supply 380V/50Hz, 3 Phase
Basket Lift System
Oscillation System
Push Arm
Independent Electrical Cabinet With HMI

Engine Parts Ultrasonic Cleaner

Engine Parts Ultrasonic Cleaner


3. Engine Parts Ultrasonic Cleaner Features and Application

1. Automatic cleaning and loading/unloading
2. Siemens centralized control system, easy to operate and use flexibly
3. Adopting Siemens, Schneider and other famous brands for electrical components in master control system
4. Ultrasonic tank with TU ultrasonic generator for cleaning more thoroughly
5. Working time, heating temperature and power level etc on each tank can be set by user
6. Material SUS304 imported from South Korea POSCO

Engine Parts Ultrasonic Cleaner


4. Details Images

Engine Parts Ultrasonic Cleaner


5. Company Qualification

Engine Parts Ultrasonic Cleaner

Engine Parts Ultrasonic Cleaner


6. Deliver, Shipping and Serving

Engine Parts Ultrasonic Cleaner

Engine Parts Ultrasonic Cleaner

The packing is adopting exportable wooden box or pallet, wrapped with moisture-proof material which can protect the machine from dust and moisture during sea shipment.

Engine Parts Ultrasonic Cleaner


7. FAQ

1. Are you manufacturer or trading company?
We are manufacturer. All the core components (ultrasonic transducer, ultrasonic generator) are home-made by ourselves.
2. Do you accept OEM and ODM?
Yes, we also have profession R&D teams (ultrasonic transducer team, ultrasonic generator team and mechanical design team) to responds your special needs quickly.
3. Delivery time
Standard products can be delivered within 7 working days. Customized machine depend on the design.
4. Warranty
We guarantee quality of the products for a period of 1 year. If any quality problem within warranty, we’ll provide free spare parts or repairing service.
5. Do you provide trial cleaning service?
Yes, you're welcome to send the workpieces for trial cleaning. We'll send you video and report about the test. It’s free service.
6. Can you provide ultrasonic transducer or generator if any failure?
Yes, ultrasonic transducer and ultrasonic generator are designed and manufactured by ourselves. We can send the right parts quickly for replacement.
7. Payment Methods?
T/T ,L/C, D/P ,D/A, West Union , Paypal, MoneyGram ,Escrow .
8. Which frequency and power is suitable for our workpiece?
Please contact us and provide details as specific as you can. Information includes: the size, material, weight and dirt of your workpiece and cleaning tank dimension etc.
