Dual Frequency Ultrasonic Cleaner

Dual frequency ultrasonic cleaner is economy, low operating costs and easy to operate, man-machine dialogue model to help you quickly and easily complete the cleaning task. The installation is only a few steps, it can be placed in almost all production areas.

Send Inquiry

PDF DownLoad

Product Description

China Dual Frequency Ultrasonic Cleaner Manufacturers with High Quality

1.Dual Frequency Ultrasonic Cleaner Introduction

Dual frequency ultrasonic cleaner is economy, low operating costs and easy to operate, man-machine dialogue model to help you quickly and easily complete the cleaning task. The installation is only a few steps, it can be placed in almost all production areas.

We focus on developing and research easy operating ultrasonic cleaner. To ensure customers have benefits from high-tech ultrasonic cleaning technology. M series ultrasonic cleaning equipment can expand or refit on existing cleaning equipment.

Clangsonic fully automatic ultrasonic cleaning equipment, available in 5 different standard size, that is single tank 50L/85L/120L/160L/220L, other sizes can be made as requests. Ultrasonic frequency available in both single frequency and dual-frequency 25/45kHz, 28/68kHz, 40/80kHz, 40/130kHz and 80/130kHz. The unit is equipped with an oscillation device for the cleaning basket which assists and improves the cleaning effect of the ultrasound, and which also provides a drip off support for the stainless-steel basket. The units of Clangsonic M series can be combined with a rinsing tank (with /without heating) and a hot air dryer of the relevant size. The units are delivered including support frame.

Dual Frequency Ultrasonic Cleaner

Clangsonic provides varies of capacities of ultrasonic cleaner. Please contact us for customized tank size.


2.Dual Frequency Ultrasonic Cleaner Parameter(Specification)

Name 2-Tank Ultrasonic Cleaning Line
Model M612
Overall Size 2500x1620x1585mm
Single Tank Inner Size 500x350x350mm
Basket Size Customizable
Basket Loading Capacity 25KG
#1 Tank 40/130kHz Ultrasonic Cleaning
#2 Tank Hot Air Drying Tank
Heating Power For #1 Tank 5000W
Heating Power For #2 Tank 3000W
Power Supply 380V/50Hz, 3 Phase
Basket Lift System
Oscillation System
Push Arm
Independent Electrical Cabinet With HMI


3. Dual Frequency Ultrasonic Cleaner Features and Application

1. Automatic cleaning and loading/unloading
2. Siemens centralized control system, easy to operate and use flexibly
3. Adopting Siemens, Schneider and other famous brands for electrical components in master control system
4. Ultrasonic tank with TU ultrasonic generator for cleaning more thoroughly
5. Working time, heating temperature and power level etc on each tank can be set by user
6. Material SUS304 imported from South Korea POSCO

Dual Frequency Ultrasonic Cleaner


4. Details Images

Dual Frequency Ultrasonic Cleaner


5. Company Qualification

Dual Frequency Ultrasonic Cleaner

Dual Frequency Ultrasonic Cleaner


6. Deliver, Shipping and Serving

Dual Frequency Ultrasonic Cleaner

Dual Frequency Ultrasonic Cleaner

The packing is adopting exportable wooden box or pallet, wrapped with moisture-proof material which can protect the machine from dust and moisture during sea shipment.

Dual Frequency Ultrasonic Cleaner


7. FAQ

1. Are you manufacturer or trading company?
We are manufacturer. All the core components (ultrasonic transducer, ultrasonic generator) are home-made by ourselves.
2. Do you accept OEM and ODM?
Yes, we also have profession R&D teams (ultrasonic transducer team, ultrasonic generator team and mechanical design team) to responds your special needs quickly.
3. Delivery time
Standard products can be delivered within 7 working days. Customized machine depend on the design.
4. Warranty
We guarantee quality of the products for a period of 1 year. If any quality problem within warranty, we’ll provide free spare parts or repairing service.
5. Do you provide trial cleaning service?
Yes, you're welcome to send the workpieces for trial cleaning. We'll send you video and report about the test. It’s free service.
6. Can you provide ultrasonic transducer or generator if any failure?
Yes, ultrasonic transducer and ultrasonic generator are designed and manufactured by ourselves. We can send the right parts quickly for replacement.
7. Payment Methods?
T/T ,L/C, D/P ,D/A, West Union , Paypal, MoneyGram ,Escrow .
8. Which frequency and power is suitable for our workpiece?
Please contact us and provide details as specific as you can. Information includes: the size, material, weight and dirt of your workpiece and cleaning tank dimension etc.
